Throughput Transmission Fiber Spectrometer 532nm Confocal Raman Microscopy 6kg Weight

Contact Now

Throughput Transmission Fiber Spectrometer 532nm Confocal Raman Microscopy 6kg Weight

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	Customized Packaging	Delivery Time :	40-70working days
Payment Terms :	T/T, Western Union	Supply Ability :	80 PCS/70-90 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	ISO9001	Model Number:	ST90S
Document:	Product Brochure PDF

Detail Information
Wavelength Range:	532nm~680nm (260~4200cm-1	Focal LengthTime:	90mm
Detector:	PI Pixis 100BX	Effective Pixel:	1340*100
Highlight:	Throughput Transmission Fiber Spectrometer , Fiber Spectrometer 532nm , 532nm Confocal Raman Microscopy

Product Description

High-Throughput Transmission Fiber Spectrometer 532nm Confocal Raman Microscopy

Key Specifications

Wavelength Range	532nm~680nm (260~4200cm-1)
Focal Length	90mm
Detector	PI pixis 100BX
Effective Pixel	1340*100
Weight	6kg

Product Overview

The High-Throughput Transmission Raman Spectrometer features a VPH Volume Holographic Transmission Grating for superior spectral resolution and throughput. With an optical resolution of 0.25nm (8cm-1 at 50μm slit), it delivers precise measurements across a broad wavelength range of 540nm~686nm (260~4200cm-1).

Key Features

Modular design for easy integration into existing setups
Deep cooling 532nm Raman Spectrometer Module
High diffraction efficiency (>85%) with VPH grating
Zero-aberration design with diffraction-limited resolution
Compatible with SMA905 or Φ10mm multi-core optical fiber
Ultra-low dark current and noise for research-grade performance

Technical Parameters

Product Name	High-Throughput Transmission Raman Spectrometer
Product Category	Fiber Optic Spectrometers
Optical Resolution	0.25nm (8cm-1 at 50μm slit)
Numerical Aperture	0.25
Integration Time	1ms-3600s
Dimensions	348.7mm × 222.8mm × 126mm

Applications

This research-grade spectrometer is ideal for:

532nm Confocal Raman microscopy
Industrial process analysis and online gas detection
Chemical industry applications
Online biopharmaceutical analysis
Academic and laboratory research

Manufacturer Information

JINSP Technology, originating from Tsinghua University with 17 years of spectroscopic technology experience, offers this certified (ISO9001) product as part of their extensive range. With over 3,000 units sold worldwide, their products are exported to more than 30 countries.

Ordering Information

Model Number	ST90S
Minimum Order Quantity	1 unit
Price	Negotiable
Payment Terms	T/T, Western Union
Delivery Time	40-70 working days
Supply Ability	80 PCS/70-90 days

Support & Services

Remote technical support via phone or email
On-site installation and training
Repair and calibration services
Customization options for specific applications

Packaging & Shipping

The spectrometer is securely packaged in sturdy cardboard with protective cushioning, labeled with product specifications for easy identification. Custom packaging options are available.
