JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses
JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses
Contact Now

JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses

Minimum Order Quantity : 1 Price : Negotiable
Packaging Details : 1PC/BOX Delivery Time : 80-90 Working days
Payment Terms : T/T Supply Ability : 20PCS / 80-90Working days
Place of Origin: CHINA Brand Name: JINSP
Certification: CE ISO9001 Model Number: LS1210 LS1220
Document: Product Brochure PDF

Detail Information
Wave Length: 532nm Repetition Rate: 1kHz ~ 5kHz
Pulse Width: 50 ± 20nm Power Stability: <1.5%
Beam Quality: M2<1.5 Beam Divergence: 0.2±0.05(mrad)
Cooling Method: Water Average Power(: 40W ,120W, 150W Three Options
Highlight:

nanosecond pulsed fiber laser

,

1kHz Nanosecond Long Pulse Laser

,

5kHz Nanosecond Long Pulse Laser

Product Description

JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses
Technical Specifications
Attribute Value
Wave length 532nm
Repetition Rate 1kHz ~ 5kHz
Pulse Width 50 ± 20nm
Power Stability <1.5%
Beam quality M2<1.5
Beam Divergence 0.2±0.05(mrad)
Cooling Method Water
Average Power 40W, 120W, 150W three options
Nano-Second Long Pulse Width Solid-State Laser
The JINSP LS1200 Series represents a comprehensive range of diode-pumped solid-state lasers in the medium to high power spectrum, capable of producing both continuous wave and pulsed laser outputs. These advanced lasers feature a sophisticated water cooling system that ensures optimal performance and longevity by maintaining stable operating temperatures. Utilizing a slab architecture design, they enhance efficiency and beam quality with an active medium of Neodymium-doped Yttrium Aluminum Garnet (Nd:YAG), renowned for its excellent lasing properties.
Designed for versatility, the LS1200 Series can operate as a standalone integrated laser system or as a foundational laser seed source for amplification to higher power requirements. This dual functionality makes it suitable for diverse applications including industrial cutting and welding, scientific research, medical procedures, and military applications.
Product Selection & Parameters
Product code LS1210 LS1320
1kHz 3kHz 5kHz 1kHz 3kHz 5kHz
Wavelength(nm) 532
Average Power (W) 10 30 37 40 120 150
Peak Power (MW) 0.17 0.14 0.1 0.67 0.57 0.39
Single Pulse Energy(mJ) 10 10 7.4 40 40 30
Pulse Width (ns) 50 ± 20
Size of Nearfield Beam ~5 (nm)
Beam Divergence 0.2±0.05(mrad)
Beam Quality M2＜ 1.5 1.8
Linewidth 40 (GHz)
Polarization Linear
Warm-up Time ~10 (min)
Applications
  • Scientific Research: Atomic physics, spectroscopy, particle physics
  • Instrument Components: Laser amplifier seed sources, fundamental frequency light for frequency doubling, Raman spectroscopy
  • Industrial Manufacturing: Material processing, laser cutting, laser marking
  • Medical Field: Laser surgery, skin beautification, ophthalmic surgery
JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses 0 JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses 1 JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses 2
Laser Processing Advantages
  • Non-contact: Avoids material scratches or wear
  • High Precision: Concentrated energy for accurate targeting
  • High Efficiency: Quick contaminant removal without disassembly
  • Controllability: Adjustable parameters for different materials
  • Environmentally Friendly: Eliminates chemical solvents
JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses 3 JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses 4 JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses 5 JINSP LS1200 Series Nanosecond Long Pulse Laser 50 ± 20nm Pulse Width and 1kHz 5kHz Repetition Rate for Multiple Uses 6
Frequently Asked Questions
Q1: This is the first time I use it, is it easy to operate?
We provide an English manual and guide video, along with professional technical support from our engineers.
Q2: Can you offer an operation training?
Training is available at our factory or we can arrange for our engineers to provide on-site support including installation, training, and maintenance.
Q3: How to receive the best price in the shortest time?
Please provide detailed specifications (wavelength, detector type, effective pixels, focal length) in your inquiry for an accurate quotation.
Q4: If the spectrometer has a problem in my place, what could I do?
The product includes a one-year warranty with free repairs. Our technicians will diagnose issues based on your feedback.
Q5: What about quality assurance?
All products undergo rigorous quality inspection before shipment, with documentation available upon request.
