Stable and Accurate Nonplanner Ring Oscillator Laser for Gravitational Wave Detection

Contact Now

Stable and Accurate Nonplanner Ring Oscillator Laser for Gravitational Wave Detection

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	International Shipping Package	Delivery Time :	90-120 Working days
Payment Terms :	T/T	Supply Ability :	20PCS / 90-120Working days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE ISO9001	Model Number:	LN1000 LN1200
Document:	Product Brochure PDF

Detail Information
Wave Length:	1064nm 532nm	Power Stability:	＜ 0.1% Or ＜ 1%
Beam Quality:	M2<1.2 M2<1.3	Beam Divergence:	0.2±0.05(mrad)
Linewidth (kHz):	1 Or 3	Power Supply Voltage (V):	220
Highlight:	Stable Nonplanner Ring Oscillator Laser , Accurate Nonplanner Ring Oscillator Laser

Product Description

Key Specifications

Attribute	Value
Wave length	1064nm 532nm
Power Stability	＜ 0.1% or ＜ 1%
Beam quality	M2<1.2 M2<1.3
Beam Divergence	0.2±0.05(mrad)
Linewidth (kHz)	1 or 3
Power supply voltage (V)	220

Narrow Linewidth Solid-State Laser

The LN series of narrow linewidth lasers delivers exceptional spectral purity, long coherence length, and minimal phase noise. These precision-engineered lasers provide stable, accurate light output for demanding scientific and industrial applications.

Product Selection Table & Parameters

Product code	LN1000	LN1200
Wavelength(nm)	1064	532 (Including iodine stabilizing system)
Average Power (W)	2	0.01 (Maximum to 0.05, Customization required)
Power Stability	＜ 0.1%	＜ 1%
Beam Divergence (mrad)	1.2 @ 3mm Beam Waist	2.3 @ 3mm Beam Waist
Beam Quality	M2 < 1.2	M2 < 1.3
Linewidth (kHz)	1	3
Polarization	Linear
Power supply voltage (V)	220
Warm-up Time (min)	~ 5	~ 10
Storage Temperature (°C)	-10 °C ~ 50°C

Advantages of Narrow Linewidth Light Sources

High-speed ultra-precision laser interferometers achieve superior measurement accuracy through:

Enhanced coherence coefficient from high-power 1064nm output
Exceptional wavelength stability for atomic-scale precision
Measurement capabilities surpassing 300mm range with subatomic accuracy

Applications

Scientific Research (Institutes and Universities)

High-precision Laser Rangefinder (Michelson Interferometer)
Laser Frequency Standard Light Source (532 System)
Precision Spectral Measurement

Core Components for Instrument Manufacturers

Ultra-narrow Linewidth Laser Seed Source

Industrial Manufacturing

High-precision Light Source
Laser Rangefinder in Integrated Circuits (532 System)

Frequently Asked Questions

Q1: This is the first time I use it, is it easy to operate?

A1: We provide comprehensive English manuals and instructional videos, along with professional technical support from our engineers.

Q2: Can you offer an operation training?

A2: We offer both on-site training at our facility and engineer support at your location for installation, training, and maintenance.

Q3: How to receive the best price in the shortest time?

A3: Please provide detailed specifications (wavelength, detector type, pixels, focal length) for an accurate, prompt quotation.

Q4: What if the spectrometer has a problem?

A4: All products include a one-year warranty with free repairs. Our technicians provide remote diagnostics and support.

Q5: What about quality assurance?

A5: Our quality inspection team performs rigorous testing before shipment, with documentation and photos available upon request.
