LN Series 1064nm 532nm Nonplanner Ring Oscillator Laser / Narrow Linewidth Solidstate Laser

Contact Now

LN Series 1064nm 532nm Nonplanner Ring Oscillator Laser / Narrow Linewidth Solidstate Laser

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	International Shipping Package	Delivery Time :	90-120 Working days
Payment Terms :	T/T	Supply Ability :	20PCS / 90-120Working days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE ISO9001	Model Number:	LN1000 LN1200
Document:	Product Brochure PDF

Detail Information
Wave Length:	1064nm 532nm	Power Stability:	<1.5%
Beam Quality:	M2<1.2 M2<1.3	Beam Divergence:	0.2±0.05(mrad)
Highlight:	532nm Oscillator Laser , Narrow Linewidth Solidstate Laser , 1064nm solid state laser

Product Description

LN Series 1064nm/532nm Nonplanar Ring Oscillator Laser

Key Specifications

Attribute	Value
Wavelength	1064nm/532nm
Power Stability	<1.5%
Beam Quality	M²<1.2 (1064nm) M²<1.3 (532nm)
Beam Divergence	0.2±0.05 mrad

Narrow Linewidth Solid-State Laser Technology

The LN series narrow linewidth lasers deliver exceptional spectral purity, long coherence length, and minimal phase noise. These precision-engineered light sources provide stable output critical for advanced scientific and industrial applications.

Technical Parameters

Parameter	LN1000 (1064nm)	LN1200 (532nm)
Average Power	2W	0.01W (max 0.05W customizable)
Power Stability	<0.1%	<1%
Beam Divergence	1.2 mrad @ 3mm beam waist	2.3 mrad @ 3mm beam waist
Linewidth	1 kHz	3 kHz
Polarization	Linear
Warm-up Time	~5 minutes	~10 minutes

Performance Advantages

Enables atomic-scale measurement precision within 300mm range
Enhances interferometer coherence coefficient for improved accuracy
Provides exceptional wavelength stability for precision measurements
Delivers high-power output with narrow linewidth characteristics

Applications

Scientific Research

High-precision laser rangefinders (Michelson interferometer)
Laser frequency standard light source (532 system)
Precision spectral measurement systems

Industrial Components

Ultra-narrow linewidth laser seed source
High-precision measurement light source
Integrated circuit laser rangefinder (532 system)

Frequently Asked Questions

Q: Is the system easy to operate for first-time users?

A: We provide comprehensive English manuals and instructional videos, along with professional technical support from our engineers.

Q: Do you offer operation training?

A: Training is available at our facility or we can provide on-site support including installation, training, and maintenance.

Q: How can I receive the best pricing?

A: Please provide detailed specifications (wavelength, detector type, focal length, etc.) for an accurate quotation.

Q: What is your warranty and support policy?

A: All systems include a one-year warranty with free repairs. Our technicians provide remote diagnostics and support.

Q: How do you ensure product quality?

A: Every unit undergoes rigorous quality inspection before shipment, with documentation available upon request.
