High-Power Nonplanner Ring Oscillator Laser for Gravitational Wave Detection and Coherent Optical Communications

Contact Now

High-Power Nonplanner Ring Oscillator Laser for Gravitational Wave Detection and Coherent Optical Communications

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	International Shipping Package	Delivery Time :	90-120 Working days
Payment Terms :	T/T	Supply Ability :	20PCS / 90-120Working days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE ISO9001	Model Number:	LN1000 LN1200
Document:	Product Brochure PDF

Detail Information
Wave Length:	1064nm 532nm	Power Stability:	<1.5%
Beam Quality:	M2<1.2 M2<1.3	Beam Divergence:	0.2±0.05(mrad)
Warm-up Time (min):	~ 5 Or ~ 10	Power Supply Voltage (V):	220
Highlight:	High Power Nonplanner Ring Oscillator Laser , Gravitational Wave Detection NPRO Laser , Coherent Optical Communications NPRO Laser

Product Description

Product Specifications

Attribute	Value
Wave length	1064nm 532nm
Power Stability	<1.5%
Beam quality	M2<1.2 M2<1.3
Beam Divergence	0.2±0.05(mrad)
Warm-up Time (min)	~ 5 or ~ 10
Power supply voltage (V)	220

Narrow Linewidth Solid-State Laser

The LN series of narrow linewidth lasers offer high spectral purity, long coherence length, and low phase noise. These lasers serve as core light sources for applications including gravitational wave detection, cold atom physics, coherent optical communications, optical precision measurements, and microwave photonic signal processing.

Product Selection & Technical Parameters

Product code	LN1000	LN1200
Wavelength(nm)	1064	532 (Including iodine stabilizing system)
Average Power (W)	2	0.01 (Maximum to 0.05, Customization required)
Power Stability	< 0.1%	< 1%
Beam Divergence (mrad)	1.2 @ 3mm Beam Waist	2.3 @ 3mm Beam Waist
Beam Quality	M2 < 1.2	M2 < 1.3
Linewidth (kHz)	1	3
Polarization	Linear
Power supply voltage (V)	220
Warm-up Time (min)	~ 5	~ 10
Storage Temperature (°C)	-10 °C ~ 50°C

Key Advantages

Measurement accuracy of high-speed ultra-precision laser interferometers is enhanced by wavelength stability and coherence coefficient
High-Power Output: 1064nm narrow linewidth light sources provide superior power output, improving interferometer coherence coefficient
High Wavelength Stability: Significantly improves measurement accuracy
Ultra-narrow linewidth enables measurement precision below atomic scale within 300mm range

Applications

Scientific Research (Institutes & Universities)

High-precision Laser Rangefinder (Michelson Interferometer)
Laser Frequency Standard Light Source (532 System)
Precision Spectral Measurement

Core Components for Laser Instruments

Ultra-narrow Linewidth Laser Seed Source

Industrial Manufacturing

High-precision Light Source
Laser Rangefinder in Integrated Circuits (532 System)

Frequently Asked Questions

Q1: This is the first time I use it, is it easy to operate?

A1: We provide an English manual and instructional video, along with professional technical support from our engineers.

Q2: Can you offer an operation training?

A2: We offer both on-site training at our facility and can send engineers to your location for installation, training, and maintenance.

Q3: How to receive the best price in the shortest time?

A3: Please provide detailed specifications (wavelength, detector, pixels, focal length) for an accurate quotation.

Q4: What if the spectrometer has a problem?

A4: Our one-year warranty covers free repairs, with technical support to diagnose issues remotely.

Q5: What about quality assurance?

A5: All products undergo rigorous quality inspection before shipment, with documentation provided.
