900nm 2500nm Near-Infrared Spectrometer for Accurate Sugar and Moisture Measurement in Fruits Sensing Area 12.8mm*0.5mm

Contact Now

900nm 2500nm Near-Infrared Spectrometer for Accurate Sugar and Moisture Measurement in Fruits Sensing Area 12.8mm*0.5mm

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	International Shipping Package	Delivery Time :	30-40 working days
Payment Terms :	T/T, Western Union	Supply Ability :	200PCS/30-40 working days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	ISO9001	Model Number:	SR100N17 SR100N25
Document:	Product Brochure PDF

Detail Information
Measurement Range:	900nm~2500nm	Wavelength Repeatability:	±0.05 Nm
Type:	Refrigerated Linear Array InGaAs	Sensing Area:	12.8mm*0.5mm
Entrance Slit Width:	5μm,10μm,25μm,50μm (customizable)	Incident Light Interface:	SMA905 Fiber Interface, Free Space
Highlight:	Moisture Measurement Near Infrared Spectrometer , 2500nm Near Infrared Spectrometer , 900nm Near Infrared Spectrometer

Product Description

900nm-2500nm Near-Infrared Spectrometer for Accurate Sugar and Moisture Measurement in Fruits

Product Specifications

Measurement Range	900nm~2500nm
Wavelength Repeatability	±0.05 nm
Type	Refrigerated linear array InGaAs
Sensing Area	12.8mm*0.5mm
Entrance Slit Width	5μm,10μm,25μm,50μm (customizable)
Incident Light Interface	SMA905 fiber interface, free space

Fruit Quality Analysis with Near-Infrared Spectroscopy

NIR-based spectral analysis enables rapid, non-destructive fruit evaluation. This advanced technology interprets light interactions to accurately profile sugar content, acidity, and moisture levels, supporting data-driven quality control and processing decisions.

Technical Specifications

Performance Indicators	SR100N17	SR100N25
Detector
Type	Refrigerated linear array InGaAs
Effective Pixel	512
Pixel Size	25μm*500μm
Sensing Area	12.8mm*0.5mm
Optical Parameters
Wavelength Range	900-1700nm	900-2500nm
Optical Resolution	3.1nm(@25μm)	6.3nm(@25μm)
Optical Design	F/4 cross-type
Numerical Aperture	0.14
Focal Length	100mm
Entrance Slit Width	5μm,10μm,25μm,50μm (customizable)
Incident Light Interface	SMA905 fiber interface, free space
Electrical Parameters
Integration Time	1ms-12s	1ms-200ms
Data Output Interface	USB2.0, UART
ADC Bit Depth	16-bit
Power Supply	DC4.9 to 5.1V(type @5V)
Operating Current	＜3A
Environmental Parameters
Operating Temperature	10°C~40°C
Storage Temperature	-20°C~60°C
Operating Humidity	＜90%RH (no condensation)
Physical Parameters
Dimensions	178mm123mm49mm
Weight	1.2kg

Measurement Technology

Light absorption in the NIR spectrum (780-2500nm) excites molecular vibrations that produce characteristic spectra. The broad peaks observed in agricultural products result from combined vibrations of functional groups, making NIR ideal for simultaneous chemical and compositional analysis.

Measurement Methods

Near-infrared reflection detection: Suitable for surface analysis of fruit peels (color, luster) but not internal quality assessment.
Near-infrared transmission detection: Primarily for transparent or semi-transparent samples; limited application for fruit analysis.
Near-infrared diffuse reflection detection: The most effective method for opaque, solid samples, providing spectral information that reflects internal fruit characteristics (sugar content, acidity).

Applications

Quality assessment: Precise measurement of firmness, sweetness, and acidity in fruits.
Classification: Accurate identification and sorting of different fruit varieties.
Functional fruit evaluation: Screening for fruits with special nutritional components.
Disease monitoring: Early detection of conditions like citrus Huanglongbing for preventive measures.

About JINSP Technology

JINSP Company Limited originates from Tsinghua University with 17 years of experience in spectroscopic technology development. As a leading supplier, we offer over twenty spectroscopic products for pharmaceutical, chemical, public security, and customs applications. Our products are available nationwide and exported to over 30 countries, with cumulative sales exceeding 3,000 units.

Product Portfolio

UV-VIS-NIR fiber optic spectrometers
Desktop/portable Raman analyzers for laboratory and industrial liquid & gas analysis
On-site rapid detectors for drugs, food safety, explosives, and hazardous materials

Frequently Asked Questions

Is the spectrometer easy to operate for first-time users?

We provide comprehensive English manuals and instructional videos, along with professional technical support sessions from our engineers.

Do you offer operator training?

We provide both on-site training at our facility and field support from JINSP engineers for installation, training, debugging, and maintenance.

What is your company website?

Visit us at: www.jinsptech.com

What quality assurance measures do you have?

All products undergo rigorous quality inspection before shipment, with documentation and photographic evidence available upon request.
