Hamamatsu S7031 Chip Type CCD Fiber Spectrometer High Stability

Contact Now

Hamamatsu S7031 Chip Type CCD Fiber Spectrometer High Stability

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	Customized Packaging	Delivery Time :	50-70working days
Payment Terms :	T/T, Western Union	Supply Ability :	50PCS/70-90 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE	Model Number:	SR100Q
Document:	Product Brochure PDF

Detail Information
Spectral Range:	200 - 1100 Nm	Entrance Slit Width:	10μm ，25μm ，50μm ，100μm ，200μm
Humidity:	0~90%RH	High Quantum Efficiency:	92%peak@650nm, 83%@232nm
Operating Current:	<3.5A	Weight:	1200g
Highlight:	Hamamatsu S7031 Chip Fiber Spectrometer , Hamamatsu S7031 Chip ccd based spectrometer , Fiber Spectrometer High Stability

Product Description

Hamamatsu S7031 Chip Type CCD Fiber Spectrometer High Stability

Key Specifications

Spectral Range	200 - 1100 nm
Entrance Slit Width	10μm, 25μm, 50μm, 100μm, 200μm
Humidity Tolerance	0~90%RH
Quantum Efficiency	92% peak @650nm, 83% @232nm
Operating Current	<3.5A
Weight	1200g

Product Overview

The Hamamatsu S7031 CCD Fiber Spectrometer is a high-end scientific instrument designed for precision spectral analysis in demanding environments. Featuring an area array back-illuminated refrigeration chip, this spectrometer delivers exceptional sensitivity and stability across a wide wavelength range.

Core Features

High signal-to-noise ratio for precise low-intensity light detection
Humidity resistant design (0-90%RH) for laboratory and industrial use
Multiple data interfaces: USB3.0, RS232, RS485, and 20pin connector
Modular design with customizable entrance slit widths
Compact dimensions (180×120×50mm) for easy integration

Technical Parameters

Brand Name	JINSP
Model Number	SR100Q CCD Fiber Optic Spectrometer
Chip Type	Area Array Back-illuminated Refrigeration, Hamamatsu S7031
Focal Length	≤100mm
Dimensions	180mm × 120mm × 50mm
Certification	CE Certified

Applications

The SR100Q spectrometer is ideal for:

Absorption, transmittance, and reflectance detection
Light source and laser wavelength analysis
Fluorescence spectrum and Raman spectroscopy
Petrochemical monitoring and food additive testing
Material analysis and environmental monitoring

Support & Services

Our comprehensive support includes:

Installation assistance and troubleshooting
Calibration and testing services
Software updates and upgrades
Repair and maintenance services
Training and educational resources

Packaging & Shipping

Each spectrometer includes:

CCD Fiber Spectrometer unit
Power supply
User manual
USB cable
Calibration certificate

Shipping options:

Ships within 2 business days
Free shipping within the United States
International shipping available

Frequently Asked Questions

Q: What is the brand name of the CCD Fiber Spectrometer?

A: The brand name is JINSP.

Q: What is the model number?

A: The model number is SR100Q CCD Fiber Optic Spectrometer.

Q: Is the product certified?

A: Yes, it is CE certified.

Q: Where is the product made?

A: The spectrometer is manufactured in China.

Q: What are the payment options?

A: We accept T/T and Western Union payments.
