High SNR CCD Fiber Spectrometer For Precise Light Source And Laser Wavelength Detection

Contact Now

High SNR CCD Fiber Spectrometer For Precise Light Source And Laser Wavelength Detection

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	Customized Packaging	Delivery Time :	50-70working days
Payment Terms :	T/T and Western Union	Supply Ability :	50PCS/70-90 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE ISO9001	Model Number:	SR100Q
Document:	Product Brochure PDF

Detail Information
Measurement Range:	200-1100 Nm	Wavelength Accuracy:	±0.3 Nm
Optical Interface:	FC/PC Or SMA905	Operating Current:	<3.5A
Highlight:	High SNR Fiber Spectrometer , High SNR ccd based spectrometer , Precise Detection Fiber Spectrometer

Product Description

High SNR CCD Fiber Spectrometer For Precise Light Source And Laser Wavelength Detection

Key Specifications

Measurement Range	200-1100 nm
Wavelength Accuracy	±0.3 nm
Optical Interface	FC/PC or SMA905
Operating Current	<3.5A

Product Overview

The SR100Q High Sensitivity CCD Fiber Spectrometer delivers exceptional performance for precise spectral analysis across a wide 200-1100nm wavelength range. With ultra-low dark noise and a remarkable 1000:1 signal-to-noise ratio, this instrument provides researchers with reliable, accurate data for demanding applications.

Technical Features

Key Features	High Signal-to-noise Ratio (1000:1)
Humidity Range	0~90%RH
Quantum Efficiency	92% peak @650nm, 83%@232nm
Data Interfaces	USB3.0, RS232, RS485, 20pin connector
Weight	1200g
Model Number	SR100Q CCD Fiber Optic Spectrometer

Applications

Scientific Research

Ideal for fluorescence spectrum analysis, Raman spectroscopy, and precise wavelength measurement in biology, chemistry, and physics laboratories.

Industrial Quality Control

Perfect for petrochemical monitoring, food additive testing, and material composition analysis with high sensitivity detection.

Environmental Analysis

Effective for measuring pollutant concentrations in air, water, and soil samples with exceptional spectral resolution.

Medical Diagnostics

Capable of analyzing blood samples, detecting abnormalities, and studying tissue composition with precise spectral data.

Support & Services

Professional installation guidance and support
Precision calibration services
Comprehensive product training
Technical troubleshooting
Repair and replacement services
Software updates and product upgrades

Ordering Information

Brand: JINSP

Model: SR100Q

Certification: CE certified

Origin: China

Minimum Order: 1 unit

Price: Negotiable

Delivery: 50-70 working days

Frequently Asked Questions

What payment methods do you accept?

We accept T/T and Western Union payments.

What is your production capacity?

We can supply 50 units within 70-90 days.

Can the packaging be customized?

Yes, we offer customized packaging solutions.
