High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed
High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed
Contact Now

High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed

Minimum Order Quantity : 1 Price : Negotiable
Packaging Details : Customized Packaging Delivery Time : 90-120 working days
Payment Terms : T/T, Western Union Supply Ability : 5PCS/90-120 days
Place of Origin: CHINA Brand Name: JINSP
Certification: ISO9001 Model Number: SR100Q
Document: Product Brochure PDF

Detail Information
Spectrual Range: 185~1100nm(can Be Customized) Weight: 1.7kg
Model Name: SR100Q Ultra High Sensitivity Fiber Optic Spectrometer Chip Type: Back-illuminated TE-cooled Hamamatsu S7031
Effective Pixels: 1024*122 Sensing Area: 24.576*2.928mm
Highlight:

High Sensitivity Fiber Optical Spectrometer

,

Low Noise Fiber Optical Spectrometer

,

High Speed Fiber Optical Spectrometer

Product Description

SR100Q Ultra High Sensitivity Fiber Optic Spectrometer
Product Overview

The JINSP SR100Q spectrometer integrates the Hamamatsu S7031 scientific-grade TE-cooled area array CCD chip. With 24×24μm pixel size and up to 92% quantum efficiency, it delivers exceptional UV band response, significantly enhancing sensitivity and SNR for weak signals. The advanced optical path design combined with low-noise, high-speed FPGA signal processing ensures stable, reliable performance and excellent spectral signals.

Key Specifications
Chip Type Back-illuminated TE-cooled Hamamatsu S7031
Effective Pixel 1024×122
Pixel Size 24×24 μm
Sensing Area 24.576×2.928mm
Quantum Efficiency QE 92% peak @650nm, 83% @232nm
Spectral Range 185~1100nm (customizable)
Resolution 1.2~7.7nm (customizable)
SNR 1000:1
Dimensions 185×126×53mm
Weight 1.7kg
High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed 0
Technical Characteristics
High quantum efficiency: 92% peak @650nm, 83% @232nm
High SNR: Ultra-low dark noise under long integration time, SNR up to 1000:1
Noise-free processing of weak signals in long exposure with strong environmental adaptation
Low-noise, high-speed circuit with USB3.0 interface
High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed 1
Typical Applications
  • Absorption, transmittance, and reflection spectrum detection
  • Light source and laser wavelength characterization
  • OEM product modules for fluorescence spectrum, Raman spectrum, etc.
High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed 2 High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed 3
About JINSP Company Limited

JINSP has received the National Science and Technology Commission's Scientific and Technological Achievement Appraisal Certificate, China Patent Excellence Award, and Geneva International Invention Award. As a leading provider of molecular spectroscopy solutions, we specialize in Raman Spectroscopy technology.

Our product portfolio includes:

  • UV VIS NIR fiber optic spectrometers
  • Desktop/portable and online Raman analyzers for laboratory/industrial liquid & gas analysis
  • On-site rapid detectors/identifiers based on Raman technology for pharmaceuticals, food safety, hazardous materials, etc.
High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed 4 High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed 5 High SNR SR100Q Fiber Optical Spectrometer Ultra High Sensitivity Low Noise And High Speed 6
Frequently Asked Questions
Q: Is this spectrometer easy to operate for first-time users?
A: We provide comprehensive English manuals and instructional videos. Our technical team also offers professional operation guidance sessions.
Q: Do you offer operation training?
A: We welcome your technicians for factory training. Our engineers can also provide on-site support including installation, training, debugging, and maintenance.
Q: What is your website?
A: Visit us at www.jinsptech.com
Q: What quality assurance do you provide?
A: All products undergo rigorous quality inspection before shipment. We can provide inspection photos upon request.
