Raman Spectrometers Ultra High Sensitivity Fiber Optical Spectrometer High SNR SR100Q

Contact Now

Raman Spectrometers Ultra High Sensitivity Fiber Optical Spectrometer High SNR SR100Q

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	Customized Packaging	Delivery Time :	90-120 working days
Payment Terms :	T/T, Western Union	Supply Ability :	5PCS/90-120 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	ISO9001	Model Number:	SR100Q
Document:	Product Brochure PDF

Detail Information
Model Name:	SR100Q Ultra High Sensitivity Fiber Optic Spectrometer	Focal Length:	100nm
Entrance Slit Width:	10μm,25μm,50μm,100μm,200μm(customizable)	Operating Temperature:	10°C~40°C
Storage Temperature:	-20°C~60°C	Dimensions:	185mm126mm53mm
Highlight:	High SNR Fiber Optical Spectrometer , High Sensitivity Fiber Optical Spectrometer , Ultra High Sensitivity Raman Spectrometers

Product Description

SR100Q Ultra High Sensitivity Fiber Optic Spectrometer

Product Specifications

Attribute	Value
Model Name	SR100Q Ultra High Sensitivity Fiber Optic Spectrometer
Focal Length	100nm
Entrance Slit width	10μm,25μm,50μm,100μm,200μm(customizable)
Operating Temperature	10°C~40°C
Storage Temperature	-20°C~60°C
Dimensions	185mm126mm53mm

Technical Description

The JINSP SR100Q spectrometer integrates the Hamamatsu S7031, a scientific-grade TE-cooled area array CCD chip. With a pixel size of 24*24μm and quantum efficiency up to 92%, it delivers exceptional response in the ultraviolet band while significantly improving sensitivity and SNR for weak signals.

The advanced high-resolution optical path combined with a low-noise, high-speed FPGA signal processing chip ensures excellent spectral signals and stable, reliable performance. The TE cooling system dramatically reduces dark noise, making it ideal for weak light detection in scientific research applications.

Detailed Specifications

Chip Type	Back-illuminated TE-cooled Hamamatsu S7031
Fiber interface	SMA905, free space
Integration Time	1ms-2100s
Focal Length	USB3.0,RS232,RS485,20pin connector
Operating Humidity	< 90%RH (no condensation)
Weight	1.7kg

Typical Applications

Absorption, transmittance and reflection spectrum detection
Light source and laser wavelength characterization
OEM product modules for fluorescence spectrum and Raman spectrum analysis

JINSP is a professional leading solution provider in molecular spectroscopy, specializing in Raman Spectroscopy for many years. Our product portfolio includes:

UV VIS NIR fiber optic spectrometers
Desktop/portable and online Raman analyzers for laboratory or industrial liquid & gas analysis
On-site rapid detectors/identifiers based on Raman technology for various applications including drug detection, food safety, hazardous materials identification, and pharmaceutical industry solutions

Frequently Asked Questions

Q1: Can you provide operation training?

A1: Your technicians can receive training at our factory. JINSP engineers also provide on-site support including installation, training, debugging, and maintenance.

Q2: What is your website?

A2: Visit us at: www.jinsptech.com

Q3: What about your quality assurance?

A3: Our dedicated quality inspection team thoroughly checks all goods before shipment. We can provide inspection photos upon request.

Q4: Which payment methods do you accept?

A4: We accept T/T, Paypal, Western Union, L/C, and other standard payment methods.
