High Resolution Mini Spectrometer For UV Visible And Near-Infrared Spectra Detection

Contact Now

High Resolution Mini Spectrometer For UV Visible And Near-Infrared Spectra Detection

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	Customized Packaging	Delivery Time :	30-50working days
Payment Terms :	T/T, Western Union	Supply Ability :	100 PCS/70-90 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE	Model Number:	SR75C
Document:	Product Brochure PDF

Detail Information
Numerical Aperture:	0.085	Flexible Application:	Supports Output Of Spectrum Data Via USB And Serial Port,to Integrate The Applications
Chip Type:	Linear Array CMOS, Hamamatsu S11639	Dimensions:	110mm95mm40.5mm
Optical Design:	M Type C-T Light Path	Operating Humidity:	＜90%RH (no Condensation)
Highlight:	High Resolution Mini Spectrometer , High Resolution compact spectrometer , Spectra Detection Mini Spectrometer

Product Description

High Resolution Mini Spectrometer For UV Visible And Near-Infrared Spectra Detection

Key Specifications

Attribute	Value
Numerical Aperture	0.085
Flexible Application	Supports output of spectrum data via USB and serial port
Chip Type	Linear array CMOS, Hamamatsu S11639
Dimensions	110mm × 95mm × 40.5mm
Optical Design	M Type C-T light path
Operating Humidity	<90%RH (no condensation)

Product Overview

The Universal Compact Fiber Spectrometer is a high-performance handheld mini spectrometer designed for UV visible and near-infrared spectra detection. Featuring customizable entrance slit widths (10μm, 25μm, 50μm, 100μm, 200μm) and an M Type C-T light path optical design, it delivers outstanding stability and repeatability for precise measurements in various conditions.

Technical Parameters

Parameter	Specification
Chip Type	Linear array CMOS, Hamamatsu S11639
Temperature Stability	Integrated Temperature Sensor and Temperature Drift Compensation Algorithm
Spectral Range	Customizable 200-1000nm
Signal Quality	Low-noise CMOS signal processing circuit with excellent signal-to-noise ratio
Effective Pixel	2048
Optical Design	M Type C-T light path
Numerical Aperture	0.085

Applications

The JINSP SR75C spectrometer is ideal for diverse applications including:

Medical research and diagnostics
Environmental monitoring
Food quality inspection
Industrial quality control

Ordering Information

Model: JINSP SR75C
Certification: CE certified
Origin: China
Minimum Order Quantity: 1 PC
Delivery Time: 30-50 working days
Packaging: Customizable to client requirements

Support & Services

Our comprehensive support package includes:

Technical assistance and troubleshooting
Calibration and maintenance services
Operator training and education
Performance optimization guidance

Frequently Asked Questions

What is the brand name of this spectrometer?

The brand name is JINSP.

What is the model number?

The model number is SR75C.

Is this spectrometer CE certified?

Yes, it is CE certified.

Where is this spectrometer made?

It is manufactured in China.

What is the minimum order quantity?

The minimum order quantity is 1 unit.
