Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm
Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm
Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm
Contact Now

Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm

Minimum Order Quantity : 1 Price : Negotiable
Packaging Details : Customized Packaging Delivery Time : 30-50 working days
Payment Terms : T/T, Western Union Supply Ability : 100 PCS/70-90 days
Place of Origin: CHINA Brand Name: JINSP
Certification: CE Model Number: SR50C
Document: Product Brochure PDF

Detail Information
Spectral Range: 200-1100 Nm Fiber Interface: SMA905, Free Space
Integration Time: 1 Ms - 60 S Signal-to-Noise Ratio: 650:1(4ms）
Optical Design: C-T Path Dimensions: 76mm*65mm*38mm
Highlight:

High Sensitivity Modular Fiber Optic Spectrometer

,

2048 Pixel Modular Fiber Optic Spectrometer

,

Miniature Modular Fiber Optic Spectrometer

Product Description

Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm
Key Specifications
Spectral Range 200-1100 nm
Fiber Interface SMA905, free space
Integration Time 1 ms - 60 s
Signal-to-Noise Ratio 650:1 (4ms)
Optical design C-T path
Dimensions 76mm × 65mm × 38mm
Product Overview

The JINSP multi-purpose compact fiber optic spectrometer combines small size with high performance and versatility. Ideal for building spectral measurement systems, it enables reflection, transmission, and absorption spectra analysis across 200-1100 nm ranges.

Featuring industry-leading diffraction blazed grating and optical design, this spectrometer delivers high luminous flux and enhanced weak signal detection. The 2048-pixel high quantum efficiency CMOS chip with professional signal processing circuitry ensures optimal spectral signal-to-noise ratio.

Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm 0
Technical Parameters
Detector Specifications
Chip Type Linear array CMOS, Hamamatsu S11639
Effective Pixel 2048
Pixel Size 14μm × 200μm
Sensing Area 28.7mm × 0.2mm
Optical Parameters
Numerical Aperture 0.14
Focal Length ≤ 50mm
Entrance Slit Width 10μm, 25μm, 50μm, 100μm, 200μm
Electrical Parameters
Integration Time 1ms-60s
Signal-to-Noise Ratio 650:1 (4ms)
Data Output Interface Type-C
ADC Bit Depth 16-bit
Power Supply DC 4.5V to 5.5V (type @5V)
Model Variations
Model Spectral Range Resolution Slit
SR50C-G01 200-1000nm (UV-NIR) 1.5-3.5nm 10-50μm
SR50C-G03 350-870nm (VIS) 1.2-2.5nm 10-50μm
SR50C-G04/G07/G08 200-1050nm (UV-VIS-NIR) 0.8-1.8nm 10-50μm
SR50C-G09/G10 200-700nm (UV-VIS) 0.3-1.0nm 10-50μm
Key Features
  • Wide spectral range covering 200-1100nm
  • High signal-to-noise ratio with low-noise CMOS processing
  • Compact dimensions (79×68×42mm) and lightweight (220g)
  • Multiple slit width options for resolution adjustment
  • Type-C interface for convenient data transfer
Applications
  • Absorption, transmittance and reflectivity measurements
  • Light source and laser wavelength identification
  • Environmental monitoring (smoke, water quality)
  • LIBS, fluorescence and Raman spectroscopy
  • OEM integration for analytical systems
Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm 1 Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm 2
Certifications & Awards

JINSP Company Limited holds multiple prestigious awards including:

  • National Science and Technology Commission's Scientific Achievement Certificate
  • China Patent Excellence Award
  • Geneva International Invention Award

Certifications include:

ISO9001:2015 ISO14001:2015 ISO45001:2018 CE Certification

Complies with GB/T 40219-2021 "General Specification for Raman Spectrometer".

Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm 3 Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm 4 Miniature Modular Fiber Optic Spectrometer SR50C High Sensitivity 2048 Pixel 200nm - 1100nm 5
Frequently Asked Questions
Q: What is the brand name of this fiber spectrometer?
A: JINSP is the brand name of this fiber spectrometer.
Q: What is the model number of this fiber spectrometer?
A: The model number is SR50C.
Q: What certification does this fiber spectrometer have?
A: This spectrometer has CE certification.
Q: Where is this fiber spectrometer made?
A: Manufactured in China.
Q: What are the payment terms for this product?
A: Payment terms include T/T and Western Union. Prices are negotiable.
