High Accuracy Mini Raman Spectrometer Integrated Temperature Sensor And Compensation

Contact Now

High Accuracy Mini Raman Spectrometer Integrated Temperature Sensor And Compensation

Minimum Order Quantity :	1	Price :	Negotiable
Packaging Details :	Customized Packaging	Delivery Time :	30-50working days
Payment Terms :	T/T, Western Union	Supply Ability :	100 PCS/70-90 days

Place of Origin:	CHINA	Brand Name:	JINSP
Certification:	CE	Model Number:	SR75C
Document:	Product Brochure PDF

Detail Information
Dimensions:	110mm95mm40.5mm	Wide Spectral Range:	Supports Customized Spectrum Range Of 200-1000nm
Low Temperature Drift:	Integrated Temperature Sensor And Temperature Drift Compensation Algorithm	Chip Type:	Linear Array CMOS, Hamamatsu S11639
High Signal-to-Noise Ratio:	Low-noise CMOS Signal Processing Circuit, With Excellent Signal-to-noise Ratio	Sensing Area:	28.7mm *0.2mm
Highlight:	High Accuracy Mini Raman Spectrometer , High Accuracy compact raman spectrometer , Integrated Temperature Sensor Mini Raman Spectrometer

Product Description

High Accuracy Mini Raman Spectrometer with Integrated Temperature Sensor

Key Features

Compact dimensions: 110mm × 95mm × 40.5mm
Wide spectral range: Customizable 200-1000nm
Integrated temperature sensor with drift compensation
High-performance Hamamatsu S11639 CMOS chip
Excellent signal-to-noise ratio with low-noise processing
Sensing area: 28.7mm × 0.2mm

Technical Specifications

Attribute	Specification
Product Name	Universal Compact Fiber Spectrometer
Spectral Range	200-1000nm (customizable)
Dimensions	110mm × 95mm × 40.5mm
Numerical Aperture	0.085
Chip Type	Linear array CMOS (Hamamatsu S11639)
Sensing Area	28.7mm × 0.2mm
Signal-to-Noise Ratio	Low-noise CMOS processing with excellent performance

Advanced Optical Design

The spectrometer features an M-shape C-T optical design for high-resolution analysis with minimal stray light. Optimized for optical fiber integration, this design ensures versatility across various spectroscopy applications.

Customizable Options

Adjustable entrance slit width (10μm, 25μm, 50μm, 100μm, 200μm)
Lightweight design (310g) for easy transport
Data output via USB and serial port

Applications

Raman spectroscopy systems
Fluorescence and absorbance measurements
Laboratory research and medical diagnosis
Environmental protection monitoring
Food safety detection

Support & Services

Expert consultation services
Comprehensive training programs
On-site installation and commissioning
Calibration and repair services

Frequently Asked Questions

Q: What is the brand and model of this spectrometer?

A: Brand name is JINSP, model number SR75C.

Q: Is the spectrometer certified?

A: Yes, it is CE certified.

Q: What are the ordering details?

A: Minimum order quantity is 1 unit. Delivery time is 30-50 working days. Payment options include T/T and Western Union.

For more information about this high-performance fiber spectrometer or to discuss your specific application requirements, please contact our technical team.
