Lightweight Universal Compact Fiber Optic Spectrometer High Performance
Lightweight Universal Compact Fiber Optic Spectrometer High Performance
Lightweight Universal Compact Fiber Optic Spectrometer High Performance Lightweight Universal Compact Fiber Optic Spectrometer High Performance
Contact Now

Lightweight Universal Compact Fiber Optic Spectrometer High Performance

Minimum Order Quantity : 1 Price : Negotiable
Packaging Details : Customized Packaging Delivery Time : 30-50working days
Payment Terms : T/T, Western Union Supply Ability : 100 PCS/70-90 days
Place of Origin: CHINA Brand Name: JINSP
Certification: CE Model Number: SR50C
Document: Product Brochure PDF

Detail Information
Dimensions: 79mm*68mm*42mm High Resolution: M-shape C-T Optical Design
Wide Spectral Range: Supports Customized Spectrum Range Of 200-1000nm Weight: 220g
Fiber Input: FC/PC Or SMA905 Power Consumption: 12 VDC, 1.5 A
Spectral Range: 200~1000（UV-NIR） Detector Type: Back-Illuminated CCD
Highlight:

Lightweight Fiber Optic Spectrometer

,

Fiber Optic Spectrometer High Performance

,

Lightweight optical fiber spectrometer

Product Description

Lightweight Universal Compact Fiber Optic Spectrometer High Performance
Product Specifications
Attribute Value
Dimensions 79mm × 68mm × 42mm
High Resolution M-shape C-T optical design
Wide Spectral Range Supports customized spectrum range of 200-1000nm
Weight 220g
Fiber Input FC/PC or SMA905
Power Consumption 12 VDC, 1.5 A
Spectral Range 200~1000nm (UV-NIR)
Detector Type Back-Illuminated CCD
Product Overview

The JINSP SR50C Miniature Fiber Optic Spectrometer is a compact, high-performance instrument designed for achieving reflection, transmission, and absorption spectra in the 200–1100nm range. It enables high-resolution spectral detection in UV, Visible, and near-Infrared spectrum through adjustable grating line density and interchangeable grating slits.

Equipped with a fast, low-noise signal acquisition circuit, the spectrometer delivers spectra with exceptional signal-to-noise ratio (SNR). Its advanced optical design and blazed diffraction grating ensure high luminous flux and enhanced sensitivity to weak signals.

Lightweight Universal Compact Fiber Optic Spectrometer High Performance 0 Lightweight Universal Compact Fiber Optic Spectrometer High Performance 1
Technical Specifications
No Item Description
1 Name SR50C Fiber Optic Spectrometer
2 Chip Type Linear array CMOS, Hamamatsu S11639
3 Effective Pixel 2048
4 Sensing Area 28.7mm × 0.2mm
5 Optical Design M Type C-T light path
6 Numerical Aperture 0.14
7 Entrance Slit Width 10μm, 25μm, 50μm, 100μm, 200μm (customizable)
8 Dimensions 76mm × 65mm × 36mm
9 Weight 220g
Typical Applications
Detection of absorption, transmittance and reflectivity of ultraviolet, visible and near infrared radiations
Light source and laser wavelength identification
Environmental protection industry (smoke and water quality monitoring)
LIBS (Laser-Induced Breakdown Spectroscopy)
Fluorescence spectrum analysis
Raman spectrum analysis
Lightweight Universal Compact Fiber Optic Spectrometer High Performance 2
Technical Characteristics
Wide Spectral Range: Customizable spectrum range of 200-1000nm
High Signal-to-Noise Ratio: Low-noise CMOS signal processing circuit
High Luminous Flux: Integrated with cylindrical mirror
Low Temperature Drift: Integrated Temperature Sensor and Compensation Algorithm
Compact Design: Small volume, lightweight with excellent performance
Lightweight Universal Compact Fiber Optic Spectrometer High Performance 3
Company Recognition

JINSP Company Limited has received numerous prestigious awards including:

National Science and Technology Commission's Scientific and Technological Achievement Appraisal Certificate
China Patent Excellence Award
Geneva International Invention Award
Beijing New Technology and New Product Certificate
"Innovation Achievement Award" of the Zhu Liangyi Analytical Instrument Innovation Award

Complies with GB/T 40219-2021 "General Specification for Raman Spectrometer".

Frequently Asked Questions
Q1: How to receive the best price in the shortest time?
A1: Please provide details including wavelength, detector type, effective pixels, and focal length when inquiring. We will promptly send a detailed quotation to your email.
Q2: What if the spectrometer has problems at my location?
A2: The spectrometer comes with a one-year warranty. Our technicians will diagnose any issues based on your feedback and provide free repairs during the warranty period.
Q3: What about quality assurance?
A3: All products undergo rigorous quality inspection before shipment. We can provide inspection photos upon request.
Q4: Do you offer operation training?
A4: Your technicians can receive training at our factory, or our engineers can provide on-site support including installation, training, debugging, and maintenance.
Q5: Do you offer OEM service?
A5: We provide OEM services including custom branding, logos, and packaging. Minimum order quantity is 200 pieces per model.
