Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type
Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type
Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type
Contact Now

Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type

Minimum Order Quantity : 1 Price : Negotiable
Packaging Details : Customized Packaging Delivery Time : 30-50working days
Payment Terms : T/T, Western Union Supply Ability : 100 PCS/70-90 days
Place of Origin: CHINA Brand Name: JINSP
Certification: CE Model Number: SR50C
Document: Product Brochure PDF

Detail Information
Weight: 220g Fiber Input Interface: SMA-905, Free Space
Fiber Type: Single Mode Or Multimode Detector Chip Type: Linear Array CMOS, Hamamatsu S11639
Operating Humidity: ＜90%RH (no Condensation) Pixel Size: 14μm *200μm
Pintegration Time: 1ms-60s Model: SR50C Fiber Spectrometer
Highlight:

Linear Array CMOS Fiber Raman Spectrometer

,

Ultra-Miniature Fiber Raman Spectrometer

,

Mini Fiber Raman Spectrometer

Product Description

SR50C Fiber Raman Spectrometer

Ultra-miniature optic mini spectrometer with linear array CMOS detector chip type, featuring compact design and high-performance light detection capabilities.

Product Specifications
Attribute Value
Weight 220g
Fiber Input Interface SMA-905, free space
Fiber Type Single mode or multimode
Detector Chip Type Linear array CMOS, Hamamatsu S11639
Operating Humidity <90%RH (no condensation)
Pixel Size 14μm *200μm
Integration Time 1ms-60s
Model SR50C Fiber spectrometer
Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type 0 Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type 1
Detailed Features
No Item Description
1 Name SR50C Fiber Optic Spectrometer
2 Chip Type Linear array CMOS, Hamamatsu S11639
3 Effective Pixel 2048
4 Sensing Area 28.7mm *0.2mm
5 Optical Design M Type C-T light path
6 Numerical Aperture 0.14
7 Entrance Slit Width 10μm, 25μm, 50μm, 100μm, 200μm (customizable)
8 Dimensions 76mm*65mm*36mm
9 Weight 220g
Technical Characteristics
Wide Spectral Range: Supports customized spectrum range of 200-1000nm
High Signal-to-Noise Ratio: Low-noise CMOS signal processing circuit
High Luminous Flux: Integrated with cylindrical mirror to improve luminous flux
Low Temperature Drift: Integrated Temperature Sensor and Temperature Drift Compensation Algorithm
Compact Design: Small volume, lightweight with excellent performance
Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type 2 Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type 3
Applications
  • Research and development laboratories
  • Quality control and assurance in manufacturing
  • Environmental monitoring
  • Food and agriculture industry
  • Medical and pharmaceuticals industry
Certifications & Awards

JINSP Company Limited has won the National Science and Technology Commission's Scientific and Technological Achievement Appraisal Certificate, China Patent Excellence Award, Geneva International Invention Award, Beijing New Technology and New Product Certificate, and the "Innovation Achievement Award" of the Zhu Liangyi Analytical Instrument Innovation Award.

Complies with GB/T 40219-2021 "General Specification for Raman Spectrometer".

Fiber Raman Spectrometer Ultra-Miniature Optic Mini Spectrometer with Linear Array CMOS Detector Chip Type 4
Frequently Asked Questions
Q: What is the brand name of this product?
A: The brand name is JINSP.
Q: What is the model number of this spectrometer?
A: The model number is SR75C.
Q: Does this product have any certification?
A: Yes, this product has CE certification.
Q: Where is this spectrometer made?
A: This spectrometer is made in China.
